How to Select the Correct Ultra-high pressure hydro-jet blasting cleaning Machine hoses

The mobile and Portable hydro-jet Ultra-high pressure chemical plants Tank cleaning machine High-pressure hose is a very important component of the high-pressure spraying cleaning equipment. It is a tool medium for high-pressure water transportation and a guarantee to ensure that high-pressure cleaning operations are efficient, safe and lasting.

It is particularly important to choose and select the high-quality high-pressure hose.

Generally when we select the Water-jet blasting automotive industry cleaning machine high pressure hose, we should take the following four aspects and factors into consideration, High Pressure grade and level, The Outside diameter and Inner diameter of high pressure hose, High pressure Hose connector, Protective Device.

1:High Pressure grade and level

First, when we select and choose the right Water-jet blasting Paint removal cleaning machine hose, we should think of the High Pressure grade and level.

Based on your high-pressure pump Max design output pressure level, You should select the high-pressure hose 20% extra-higher pressure than the Max designed output pressure.

And it should be effectively alleviate the fatigue period of high-pressure hoses and extend the service life of high-pressure hoses.

And when we choose the the high-pressure pump explosion-proof device, it also should be higher than the design pressure, which can prevent the hose from being damaged due to over-pressure failure of the high-pressure pump.

2:The Outside diameter and Inner diameter of high pressure hose

Secondly,selecting the 40000psi Pressure Water blasting cleaning machine hose, it should think about the The Outside diameter and Inner diameter of high pressure hose.

We should Select the inner diameter of the high-pressure hose according to the Max flow rate of the high-pressure pump.

A:If your high Pressure Water blasting cleaning working condition require long length of hose and the hose laying length exceeds 100 meters, the inner diameter of the hose should be appropriately increased.

B:When we choose the water-jet cleaning hose,The inner diameter of the hose should not be too large, otherwise it will increase the weight, bending radius, laying difficulty and cost of the hose;

C:When the high pressure hose come to the cases needs to be perforated or fixed, the dimensions of the hose outer diameter, crimp outer diameter and joint outer diameter need to be considered.

3:High pressure Hose connector

When we select the hydro-jet high pressure hose,high pressure hose connector is also vitally essential factor and consideration,

We should Select the type of connector according to the working pressure of the hose (straight thread/NPT/EO/M type/HP, etc.);

And Select the matching thread size according to the flow rate and hose inner diameter;

And experienced operator should Comprehensively consider the maximum allowable size range of the joint according to the operating conditions,And choose the connector material according to the use environment,because the different working condition will adapt different connector, and right connect will save you a lots of labors and avoid the further trouble.

4:Protective Device

When select 2800bar Pressure Water Jet blasting Surface Cleaning Tool high pressure hose, you should consider the protective device, because as always the safety for operator and operation is first priority.

You should Install anti-falling safety nets or anti-falling protection chains for corresponding pipe types.

The operator should Confirm whether a hose anti-wear protective sleeve is needed based on factors such as on-site usage or installation conditions.

We shenzhen Panwin Machinery&Equipment Co.Ltd is well-established Water blasting &Cutting machine components manufacturer in China,We supply you the high-grade 40000psi Pressure Water blasting cleaning machine hose at reasonable price.
